Define the building
Set the roof shape and pitch, knee height and grid bays. Select project cladding, slab and framing types, or load a saved building definition.
Built for Revit professionals
Less clicking. More building.
Turn a shed definition into a Revit model. Configure building geometry, grids, portal frames, purlins, girts, cladding and openings in one specialist workflow.
Revit 2024–2027 · Windows x6414-day trial on eligible devicesGable and mono-pitch sheds
Purpose-built for portal-frame sheds
Gable + monoRoof configurations2024–2027Supported Revit versionsIn RevitDefine, preview and generate
For workshops, warehouses and storage sheds.
Best suited to single-storey portal-frame sheds with gable or mono-pitch roofs, including workshops, warehouses and agricultural storage buildings. ClickBIM automates modelling, not structural design or engineering approval. Review the generated model against your project requirements.
How it works
Define your shed. Preview it. Build the model.
Open Add-Ins → ClickBIM → Shed in a Revit project. Select the project families and types, then work through the building, framing, grid and opening settings.
Configure the details
Choose portal-frame members, purlin and girt layouts, offsets and opening positions. Import supported PDF, DOCX or TXT documents and review extracted values before applying them.
Preview and generate
Review the building definition, then generate the corresponding model in the open Revit project. Save the definition for reuse and check the resulting elements before issuing drawings.
Designed for design changes
Adjust. Preview. Generate again.
The first generation is not the end of the workflow. Refine your building definition, review the change preview and apply another generation in the same Revit project.
- 01
Change the definition
Adjust geometry, framing or openings as the design evolves.
- 02
Review what changes
ClickBIM compares the definition with its tracked generation and previews affected phases.
- 03
Generate again
Affected phases are regenerated; unchanged phases are skipped.
Tracking applies to ClickBIM-generated elements, not every change in your project. Regeneration can replace affected elements and overwrite manual edits. Review the preview and back up your model.
Control the structure
Configure portal frames, purlins and girts using the families and types in your Revit project.
Place openings deliberately
Set opening grids and spans, dimensions, offsets and associated framing. Review placements against your building definition.
Reuse your setup
Save and reopen definitions, use Undo and Redo, switch units and themes, and consult contextual help while you work.
Simple licensing
One specialist workflow.
Choose your billing period.
Try ClickBIM for 14 days on an eligible device. Continue monthly or subscribe for a full year. Activation and periodic online licence checks protect your access.
- Shed modelling workflow inside Revit
- Updates during an active subscription
- Support through support@clickbim.com
ClickBIM MonthlyMONTHLY PLAN
$99 / month
For one machine
The specialist shed modelling workflow for Autodesk Revit.
Included features
- Shed geometry, grids and portal frames
- Purlins, girts, cladding and openings
- Save definitions and review document imports
- Updates during an active subscription
- Email support
US dollars · Taxes, billing and cancellation terms are confirmed in your order.
ClickBIM AnnualANNUAL SAVING
$1,000 / year
For one machine
A full year of the ClickBIM shed workflow for one machine.
USD 188 less than twelve monthly payments
Included features
- Shed geometry, grids and portal frames
- Purlins, girts, cladding and openings
- Save definitions and review document imports
- Updates during an active subscription
- Email support
US dollars · Taxes, billing and cancellation terms are confirmed in your order.
Company total
Equip your team. Discount the last machine.
For a company order of 2–10 machines, only the last machine is discounted: 10% × the number of machines, up to 100%. All earlier machines stay at full price. Order 10 and the last machine is free.
The company discount applies to both monthly and annual plans.
ClickBIM MonthlyUSD 267.30 / monthOff the last machine: 30%
ClickBIM AnnualUSD 2,700 / yearOff the last machine: 30%
See pricing examples
| Machines | ClickBIM Monthly | ClickBIM Annual |
|---|---|---|
| 1 | USD 99 / month | USD 1,000 / year |
| 3 | USD 267.30 / month | USD 2,700 / year |
| 10 | USD 891 / month | USD 9,000 / year |
Examples are for one company on the same plan and billing period. The discount is applied to the last machine only, not the entire order. Taxes and final order terms are confirmed by sales.
For more than 10 machines, request a company quote. No payment is taken here.
Downloads
Get the latest ClickBIM installer.
Download the installer and select your installed Revit versions during setup. Read what changed before upgrading.
ClickBIM 1.3.10
LATESTOct 9, 2026
CompatibilityRevit 2024 - 2027
Installer15.3 MB · MSI
Close Revit before installing. Back up your project before generating or updating a model. Revit 2024 end-wall roof attachment differs from Revit 2025 and later.
Before your first shed model
What buildings is ClickBIM designed for?
Single-storey portal-frame sheds with gable or mono-pitch roofs, such as workshops, warehouses and agricultural storage buildings.
Do I need Autodesk Revit?
Yes. ClickBIM is an add-in for Revit 2024–2027 on Windows x64. Open a Revit project and use suitable families and types for generation. Autodesk Revit is licensed separately.
Does it perform structural engineering?
No. ClickBIM automates modelling. You remain responsible for checking geometry, members, connections, drawings and compliance with your project requirements.
How do I start the trial?
Install ClickBIM, open its activation window and start the 14-day trial on an eligible device. Activation and periodic licence checks require an internet connection.
Can I reuse a building setup?
Yes. Save and reopen building definitions. Supported document imports let you review candidate values before applying them; they do not automatically approve a design.
From definition to model
Make your next shed a repeatable workflow.
Download ClickBIM, open a Revit project and try the shed workflow with your own families and settings.
